| MODEL NUMBER | CAPACITY (TONS) | BAIL SPREAD (FT) | HR (IN) | A (IN) | B (IN) | C (IN) | T (IN) | O (IN) | WEIGHT (LBS*) |
|---|---|---|---|---|---|---|---|---|---|
| 25-2-6 | 2 | 6 | 17 | 1.1/2 | 3 | 5 | 5/8 | 1.1/8 | 125 |
| 25-2-8 | 2 | 8 | 17 | 1.1/2 | 3 | 5 | 5/8 | 1.1/8 | 160 |
| 25-2-10 | 2 | 10 | 18 | 1.1/2 | 3 | 5 | 5/8 | 1.1/8 | 240 |
| 25-2-12 | 2 | 12 | 18 | 1.1/2 | 3 | 5 | 5/8 | 1.1/8 | 280 |
| 25-2-14 | 2 | 14 | 19 | 1.1/2 | 3 | 5 | 5/8 | 1.1/8 | 360 |
| 25-2-16 | 2 | 16 | 19 | 1.1/2 | 3 | 5 | 5/8 | 1.1/8 | 400 |
| 25-2-18 | 2 | 18 | 19 | 1.1/2 | 3 | 5 | 5/8 | 1.1/8 | 530 |
| 25-2-20 | 2 | 20 | 19 | 1.1/2 | 3 | 5 | 5/8 | 1.1/8 | 660 |
| 25-2-24 | 2 | 24 | 20 | 1.1/2 | 3 | 5 | 5/8 | 1.1/8 | 790 |
| 25-4-6 | 4 | 6 | 20 | 1.1/2 | 3 | 5 | 5/8 | 1.1/2 | 160 |
| 25-4-8 | 4 | 8 | 21 | 1.1/2 | 3 | 5 | 5/8 | 1.1/2 | 240 |
| 25-4-10 | 4 | 10 | 22 | 1.1/2 | 3 | 5 | 5/8 | 1.1/2 | 310 |
| 25-4-12 | 4 | 12 | 23 | 1.1/2 | 3 | 5 | 5/8 | 1.1/2 | 410 |
| 25-4-14 | 4 | 14 | 23 | 1.1/2 | 3 | 5 | 5/8 | 1.1/2 | 500 |
| 25-4-16 | 4 | 16 | 25 | 1.1/2 | 3 | 5 | 5/8 | 1.1/2 | 725 |
| 25-4-18 | 4 | 18 | 25 | 1.1/2 | 3 | 5 | 5/8 | 1.1/2 | 805 |
| 25-4-20 | 4 | 20 | 25 | 1.1/2 | 3 | 5 | 5/8 | 1.1/2 | 890 |
| 25-4-24 | 4 | 24 | 26 | 1.1/2 | 3 | 5 | 5/8 | 1.1/2 | 1695 |
| 25-6-6 | 6 | 6 | 28 | 1.1/2 | 3 | 5 | 3/4 | 2.1/16 | 220 |
| 25-6-8 | 6 | 8 | 29 | 1.1/2 | 3 | 5 | 3/4 | 2.1/16 | 300 |
| 25-6-10 | 6 | 10 | 29 | 1.1/2 | 3 | 5 | 3/4 | 2.1/16 | 380 |
| 25-6-12 | 6 | 12 | 31 | 1.1/2 | 3 | 5 | 3/4 | 2.1/16 | 550 |
| 25-6-14 | 6 | 14 | 31 | 1.1/2 | 3 | 5 | 3/4 | 2.1/16 | 640 |
| 25-6-16 | 6 | 16 | 31 | 1.1/2 | 3 | 5 | 3/4 | 2.1/16 | 780 |
| 25-6-18 | 6 | 18 | 31 | 1.1/2 | 3 | 5 | 3/4 | 2.1/16 | 1310 |
| 25-6-20 | 6 | 20 | 31 | 1.1/2 | 3 | 5 | 3/4 | 2.1/16 | 1450 |
| 25-6-24 | 6 | 25 | 32 | 1.1/2 | 3 | 5 | 3/4 | 2.1/16 | 1735 |
| 25-10-6 | 10 | 6 | 29 | 2 | 4 | 7 | 1 | 2.1/4 | 340 |
| 25-10-8 | 10 | 8 | 29 | 2 | 4 | 7 | 1 | 2.1/4 | 420 |
| 25-10-10 | 10 | 10 | 32 | 2 | 4 | 7 | 1 | 2.1/4 | 800 |
| 25-10-12 | 10 | 12 | 32 | 2 | 4 | 7 | 1 | 2.1/4 | 920 |
| 25-10-14 | 10 | 14 | 32 | 2 | 4 | 7 | 1 | 2.1/4 | 1100 |
| 25-10-16 | 10 | 16 | 32 | 2 | 4 | 7 | 1 | 2.1/4 | 1220 |
| 25-10-18 | 10 | 18 | 32 | 2 | 4 | 7 | 1 | 2.1/4 | 1705 |
| 25-10-20 | 10 | 20 | 32 | 2 | 4 | 7 | 1 | 2.1/4 | 1840 |
| 25-10-24 | 10 | 24 | 33 | 2 | 4 | 7 | 1 | 2.1/4 | 2230 |
| 25-15-8 | 15 | 8 | 39 | 2 | 4 | 7 | 1.1/4 | 2.1/4 | 740 |
| 25-15-10 | 15 | 10 | 39 | 2 | 4 | 7 | 1.1/4 | 2.1/4 | 865 |
| 25-15-12 | 15 | 12 | 39 | 2 | 4 | 7 | 1.1/4 | 2.1/4 | 1050 |
| 25-15-14 | 15 | 14 | 42 | 2 | 4 | 7 | 1.1/4 | 2.1/4 | 1930 |
| 25-15-16 | 15 | 16 | 42 | 2 | 4 | 7 | 1.1/4 | 2.1/4 | 2160 |
| 25-15-18 | 15 | 18 | 42 | 2 | 4 | 7 | 1.1/4 | 2.1/4 | 2290 |
| 25-15-20 | 15 | 20 | 42 | 2 | 4 | 7 | 1.1/4 | 2.1/4 | 2500 |
| 25-15-24 | 15 | ||||||||
| 25-20-8 | 20 | 8 | 36 | 2 | 4 | 7 | 1.1/4 | 3 | 830 |
| 25-20-10 | 20 | 10 | 39 | 2 | 4 | 7 | 1.1/4 | 3 | 1130 |
| 25-20-12 | 20 | 12 | 39 | 2 | 4 | 7 | 1.1/4 | 3 | 1270 |
| 25-20-14 | 20 | 14 | 39 | 2 | 4 | 7 | 1.1/4 | 3 | 1930 |
| 25-20-16 | 20 | 16 | 39 | 2 | 4 | 7 | 1.1/4 | 3 | 2200 |
| 25-20-18 | 20 | 18 | 39 | 2 | 4 | 7 | 1.1/4 | 3 | 2430 |
| 25-20-20 | 20 | ||||||||
| 25-30-8 | 30 | 8 | 54 | 2.1/2 | 5 | 9 | 1.1/2 | 3.3/4 | 1120 |
| 25-30-10 | 30 | 10 | 54 | 2.1/2 | 5 | 9 | 1.1/2 | 3.3/4 | 1325 |
| 25-30-12 | 30 | 12 | 54 | 2.1/2 | 5 | 9 | 1.1/2 | 3.3/4 | 1610 |
| 25-40-8 | 40 | 8 | 59 | 2.1/2 | 5 | 9 | 1.1/2 | 4.1/4 | 1165 |
| 25-40-10 | 40 | 10 | 59 | 2.1/2 | 5 | 9 | 1.1/2 | 4.1/4 | 1470 |
| 25-40-12 | 40 | 12 | 59 | 2.1/2 | 5 | 9 | 1.1/2 | 4.1/4 | 1700 |
