PRODUCT FEATURES:
- Beams over 4’ have 3 spreads. Outside spread, Outside less 1’, Outside less 2’.
- 3’ & 4’ beams have 2 spreads.
- Swivel hooks with hook latches standard.
- Standard capacities to 40 tons, larger capacities and configurations available.
- Complies with ASME standards.
PRODUCT OPTIONS:
- OPTION A: Extra Holes or Different Placement of Holes - Allows multiple hook positioning beyond standard 3 spreads. Specify number and spread(s) required.
- OPTION B: Faspins - For ease of positioning hooks with quick release. Specify number required.
- OPTION C: Extra Hooks - Allows for multiple pick points. Specify number required.
- OPTION D: Pin Type Bail - Lifting pin located between structural channel. (Hoist hook information must be supplied.)
- OPTION E: Shackle Lug - Lifting lug with shackle (Headroom may change.)
